Voking 1-6X24IR guns and weapons ar15 Rifle scope with Mil-Dot-Dot Reticle

FOB Reference Price:Get Latest Price
1 Piece/Pieces We accept mixed order. (Min. Order)
Supply Ability:
3000 Piece/Pieces per Month 1-6X24IR guns and weapons ar15 Rifle scope with Mil-Dot-Dot
Port:
Shanghai
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Sichuan, China (Mainland)
Brand Name:
Voking/OEM riflescope
Model Number:
V2404BIR
Type:
Rifle Scope
MODEL:
V2404BIR(1-6X24IR)
POWER:
1X-6X
OBJECTIVE:
24mm
FOV@100YDS:
30.6m-5.06m
EXITPUPIL:
16.0mm-4.0mm
EYE RELIEF:
110mm-88mm
1 CLICK@100YDS:
0.5MOA
TUBE DIA:
30mm
TUBE LENGTH:
275.7mm
OEM order:
Accepted
Packaging & Delivery
Packaging Details
1-6X24IR guns and weapons ar15 Rifle scope with Mil-Dot-Dot reticle
Cartons.Detail dimension based on the product you need.
Delivery Time
within 30 workdays after the payment

Voking 1-6X24IR guns and weapons ar15 Rifle scope with Mil-Dot-Dot Reticle



Product Description

Voking 1-6X24IR guns and weapons ar15 Rifle scope with Mil-Dot-Dot Reticle

Product Advantages:

   6x zoom range.
   Matching turrets and reticles in MOA.
   Easy Focusing Knob.
   Quick focus eyepiece.
   Second focal plane illuminated glass-etched reticle.
   30mm diameter main tube with black matte finish.
  One piece, aircraft-grade aluminum alloy construction.
  O-ring seals prevents moisture, dust and debris from penetrating.
  The flip-up covers protects exterior lenses from scratches, oil and dirt.
  Nitrogen gas is purged to prevent internal fogging over a wide range of temperatures.




Voking 1-6X24IR guns and weapons ar15 Rifle scope with Mil-Dot-Dot Reticle

Technical Data

ModelV2404BIR
Magnification1x-6x
Objective Lens Diameter24mm
Color/FinishBlack Matte
Eyepiece Diameter36.5mm
Eye Relief110mm-88mm
Exit Pupil Diameter16.0mm-4.0mm
Field of View (m@100m)33.47-5.53
Field of view (ft @100yd)100.4-16.6
MOA adjustment (one click)1/2"
Diopter Adjustment+2/-3
Tube Diameter30mm
Tube PieceSingle
Parallax Setting100yds
Windage Adjustment Range90MOA
Elevation Adjustment Range90MOA
Length279mm
Width85mm
Height85mm
Weight19.4oz
 Maximum Recoil1000G's
Lens
Lens CoatingFully Multi-coated
Number of Lenses13pcs
Lens material/typeK,ZF,BaK
Performance
Waterproof (Y / N)YES
Fogproof (Y / N)YES
Shockproof (Y / N)YES
Ocular Focus (Y / N)YES
Side Focus (Y / N)NO
Windage & Elevation Lock(Y / N)YES
Reticle
Reticle R3
Reticle Type (Etched / Wire)Etched
Focal Plane2nd
Reticle ColorBlack/Red
Illuminated(Y / N)YES
Reticle Brightness Settings0-11
Battery
Battery TypeCR2032
Battery Life80-150 hours
Battery Voltage3V
Others
Mount TypeWeaver
IP StandardIP66
Body material6061 Aluminum
Operating Temperature (°C/°F)-20 to 60 / -20 to 140
Storage Temperature (°C/°F)5 to 35 / 41 to 95
Internal Spring TypeSlice spring









Click to view more products



Packaging & Shipping



Voking 1-6X24IR guns and weapons ar15 Rifle scope with Mil-Dot-Dot Reticle

Package Contents:

1 * Filp-up covers
1 * 30mm mount rings
1 * Lense cleaning cloth
1 * User's manual
1 * Warranty card
1 * Specification Sheet
Production Process
